36v 250w 350w 48V 500W 750w bafang 8fun mid crank drive central motor e-bike conversion kit

FOB Reference Price:Get Latest Price
$295.00 - $315.00 / Sets | 1 Set/Sets (Min. Order)
Lead Time:
Quantity(Sets) 1 - 1 2 - 20 >20
Est. Time(days) 8 30 Negotiable
Report Suspicious Activity
Overview
Quick Details
Part:
Other
Place of Origin:
Jiangsu, China
Brand Name:
BAFANG
Model Number:
BBS
Nominal Voltage and power:
36v 250w/350w/500w
Bottom Bracket:
68mm/100mm/120mm
Chain wheel type:
44T/46T/48T/52T
Controller:
inside of motor
Max torque:
80N.m
Design:
brushless
Cetification:
CE
Display:
C965/C961/DPC-14
Construction:
brushless geared motor
Product Name:
36v 250w 350w bafang mid crank drive central motor
Supply Ability
Supply Ability:
5000 Unit/Units per Month
Packaging & Delivery
Packaging Details
standard export carton package for 36v 250w 350w 48V 500W 750w bafang 8fun mid crank drive central motor e-bike conversion kit.
Port
shanghai for 36v 250w 350w 48V 500W 750w bafang 8fun mid crank drive central motor e-bike conversion kit
Lead Time :
Quantity(Sets) 1 - 1 2 - 20 >20
Est. Time(days) 8 30 To be negotiated



36v 48v 250w 350w 750w bbs01 bbs02 bafang 8fun mid crank drive central motor e-bike conversion kit

Product Description



BAFANG BBS(MM G31) Mid Motor Kit



With an integrated speed sensor, this BBS(MM G31) mid-drive motor, which is compatible with standard bikes, has a rated power of 250W,350W and 500W, a reduction ratio of 1: 21.9 and a maximum torque of 80 N.m, providing ideal power for vehicles. This BBS(MM G31) mid motor need your bicycle bottom bracket is 68mm or 100mm.Light but strong and efficient, this BBS mid motor greatly enhances riding comfort and is suitable for touring bikes and commuter bikes. This BBS(MM G31) mid motor is black.



BBS Mid Motor

250w,350w,500w,750w,1000w for you to choose

BB: 68mm,100mm,110mm,120mm for you to choose



Complete kits includes:

Bafang BBS01 motor kit :

Motor:250w/350w/500w
BB:68mm,100mm for choosing
1×Mid motor
1×C965/C961 display/DPC-14/DPC-18 color display
1×Thumb throttle
1×Speed sensor
1×Chain wheel
2×Cranks
2×Brake levers
Warranty is 2 years for motor,and half year for parts
.



Detailed Images







Product Overviews



The advantage of bafang mid drive motor kit:



1.This kits can be installed on standard normal bike frame easily,no need to change the frame.
2.High starting torque,  Max torque≥80N,good performance on climbing.
3.Double clutch is used on drive unit,more safety.
4.High efficiency, low consumption,long travel distance.





Motor power36v 250w/48v 350w/500w
Bottom bracket68mm/100mm/110mm/120mm
ConstructionBrushless Geared motor
RPM83-78
Max Torque80N.m
IP-code65
Chain wheel44/46/48/52T





Product Effects







Company Information

CNEBIKES Co., Ltd is located in Changzhou city ,Jiangsu ,China.  We are just one hour from Shanghai by high-speed train . It is easy for potential customers to come and have a look at our facility and products.

We manufacture a variety of products . Our products are reliable and durable. We export to Europe, the USA, Canada, Southeast Asia, Australia and many other countries . Our customers have given us high praise for our products and service.














Packaging & Shipping



1.Packing:

Standard export carton packing, with professional foam protection.

2.Shipping:

For samples, we deliver goods to customer by UPS,FEDEX,DHL,TNT or EMS.

For mass production order, we deliver goods to customer by air or by sea.





Contact



Thank for your reading. Any questions, please contact us ASAP
