G510 bafang ultra 1000w central motor kit with DPC-18 color display

FOB Reference Price:Get Latest Price
US $560-570 / Set | 1 Set/Sets (Min. Order)
Supply Ability:
2000 Set/Sets per Month bafang ultra 1000w
Port:
Shanghai for bafang ultra 1000w
Report Suspicious Activity
Overview
Quick Details
Part:
Other
Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
Bafang
Model Number:
MMG 510
Nominal Voltag:
48V
Rated Power:
1000W
Construction:
Geared Motor
Max Torque:
160 N.m
Efficiency:
80 %
Sensor:
Speed and Torque Integrated
Chain Wheel:
44T
Controller:
Intelligent Brushless
Position:
Mid motor
Product name:
bafang ultra 1000w
Packaging & Delivery
Packaging Details
standard export carton package for bafang ultra 1000w
Delivery Time
sample 10 days after payment done for bafang ultra 1000w
Product Description



G510 bafang ultra 1000w central motor kit with DPC-18 color display





The advantage of this Mid Drive Motor:
1. 48V 1000W Torque Sensor Mid Motor
2. Comfortable Riding Experience
3. 160N.m Max Torque,Strong Climbing Ability
4. IP65 Protection Grade,No Longer Afraid of Dust and Rain
5. Simple Installation,Easy to Use,No Reluctance,Low Noise
6. DP C18.UART Color Display



Complete kit:
1x Mid Motor (Integrates Controller)
1x DP C18.UART LCD Display
1x 44T Chain Wheel
1x Speed Sensor and Magnet
1x Screws
2x Crank

1xThumb throttle(optional)

2x Brake levers(optional)



The mid-drive motot constantly samples relevant information at a frequency of up to 80k Hz via a torque sensor and two speed sensors which are all highly sensitive. The resulting data on crank torque, vehicle speed and the speed of rotation of the pedals is made available to the controller, ensuring precise control of the vehicle while achieving the highest possible efficiency. The Max Drive System puts the rider in complete control. In spite of a generous power output and a maximum torque of more than 160 N.m, the motor operates in virtual silence. The modular motor design and integrated controller make disassembly easier and improve service responsiveness. This motor can be black.

Matched Frame,please ask for quotation
